- 4 Flutes in sizes up to .2540
- 6 Flutes in sizes .2570 and up
- General purpose reaming in all materials including steel and alloys up to RC40,
Stainless, Aluminum, Brass, Bronze, and Plastics
| DESCRIPTION | PRICE | ||||||||||
| Fraction | Decimal | Flute | Overall | EDP# | Sale | ||||||
| Size | Equiv. | Length | Length | Uncoated | Qty.1 | ||||||
| 1/32 | 0.0312 | 1/4 | 1-1/2 | C36006 | $14.64 | ||||||
| 3/64 | 0.0469 | 3/8 | 1-1/2 | C36066 | $17.09 | ||||||
| 1/16 | 0.0625 | 3/8 | 1-1/2 | C36114 | $13.20 | ||||||
| 5/65 | 0.0781 | 1/2 | 1-3/4 | C36170 | $13.70 | ||||||
| 3/32 | 0.0938 | 1/2 | 2 | C36230 | $16.74 | ||||||
| 7/64 | 0.1094 | 5/8 | 2-1/4 | C36282 | $16.74 | ||||||
| 1/8 | 0.1250 | 5/8 | 2-1/4 | C36330 | $18.07 | ||||||
| 9/64 | 0.1406 | 3/4 | 2-1/2 | C36374 | $18.07 | ||||||
| 5/32 | 0.1562 | 3/4 | 2-1/2 | C36426 | $18.42 | ||||||
| 11/64 | 0.1719 | 7/8 | 2-3/4 | C36482 | $23.98 | ||||||
| 3/16 | 0.1875 | 7/8 | 2-3/4 | C36538 | $23.98 | ||||||
| 13/64 | 0.2031 | 1 | 3 | C36602 | $36.54 | ||||||
| 7/32 | 0.2187 | 1 | 3 | C36654 | $36.54 | ||||||
| 15/64 | 0.2344 | 1 | 3 | C36702 | $36.54 | ||||||
| 1/4 | 0.2500 | 1 | 3 | C36742 | $37.42 | ||||||
| 17/64 | 0.2656 | 1-1/8 | 3-1/4 | C36766 | $38.48 | ||||||
| 9/32 | 0.2812 | 1-1/8 | 3-1/4 | C36790 | $38.48 | ||||||
| 19/64 | 0.2969 | 1-1/8 | 3-1/4 | C36806 | $38.48 | ||||||
| 5/16 | 0.3125 | 1-1/8 | 3-1/4 | C36814 | $37.42 | ||||||
| 21/64 | 0.3281 | 1-1/4 | 3-1/2 | C36834 | $44.80 | ||||||
| 11/32 | 0.3438 | 1-1/4 | 3-1/2 | C36850 | $45.17 | ||||||
| 23/64 | 0.3594 | 1-1/4 | 3-1/2 | C36866 | $45.66 | ||||||
| 3/8 | 0.3750 | 1-1/4 | 3-1/2 | C36878 | $50.94 | ||||||
| 25/64 | 0.3906 | 1-1/4 | 3-1/2 | C36894 | $57.66 | ||||||
| 13/32 | 0.4062 | 1-1/4 | 3-1/2 | C36910 | $58.74 | ||||||
| 27/64 | 0.4219 | 1-3/8 | 4 | C36922 | $65.77 | ||||||
| 7/16 | 0.4375 | 1-3/8 | 4 | C36930 | $70.86 | ||||||
| 29/64 | 0.4531 | 1-3/8 | 4 | C36938 | $86.84 | ||||||
| 15/32 | 0.4688 | 1-3/8 | 4 | C36942 | $88.29 | ||||||
| 31/64 | 0.4844 | 1-1/2 | 4 | C36950 | $88.29 | ||||||
| 1/2 | 0.5000 | 1-1/2 | 4 | C36954 | $89.63 | ||||||
| 9/16 | 0.5625 | 2-1/4 | 5 | C36970 | $207.61 | ||||||
| 5/8 | 0.6250 | 2-1/4 | 5 | C36978 | $207.61 | ||||||
| 3/4 | 0.7500 | 2-1/4 | 5 | C36990 | $248.76 |
